The Biostar B350 ATX motherboard supports AMD Ryzen processors across multiple generations on the AM4 socket. With 64GB max DDR4 memory capacity at 3200MHz across 4 slots, it offers robust connectivity including PCIe 3.0 x16, M.2, and 6 SATA ports. Features include RGB support, digital PWM power delivery, and Realtek ALC892 7.1 audio. Multiple display outputs and USB 3.1 ports ensure versatile connectivity.
Specifications
Price
RM328.90
4 products(3 items sold out)
Specifications
Basic information
Brand
BIOSTAR
Model
B350
Release date
2017-02-22
Socket type
AM4
Supported processors
AMD Ryzen 1st Gen, AMD Ryzen 2nd Gen, AMD Ryzen 3rd Gen, AMD Ryzen 5th Gen
Chipset
AMD B350
Form factor
ATX
Memory
Max memory capacity
64
Max memory capacity unit
GB
Memory channels
Dual
Memory slots
4
Memory speed
3200
Memory speed unit
MHz
Memory type
DDR4
Xmp support
Ya
Environmental
Operating humidity
Unit
%
Min
20
Max
90
Operating temperature
Unit
°C
Max
60
Expansion slots
M2 slots
[{'quantity': 1, 'interface': 'PCIe 3.0 x4', 'max_speed': '32 Gb/s'}]
Pcie slots
[{'type': 'PCIe 3.0 x16', 'quantity': 1, 'speed': '16 GT/s'}, {'type': 'PCIe 2.0 x1', 'quantity': 2, 'speed': '5 GT/s'}]
Warranty support
Warranty period
3
Warranty period unit
tahun
Warranty type
Hadiah penggantian terhad
Storage
Sata ports
6
Sata speed
6 Gb/s
Features
Bios features
UEFI BIOS, BIOS Flashback
Debug features
POST State LED
Rgb headers
1
Rgb support
Yes
Connectivity
Networking
Ethernet
1 x Gigabit LAN
Wifi
Tidak
Bluetooth
Tidak
Usb ports
[{'type': 'USB 3.1 Gen1', 'quantity': 4, 'speed': '5 Gb/s'}, {'type': 'USB 2.0', 'quantity': 2, 'speed': '480 Mb/s'}]
Video outputs
Hdmi
1
Displayport
1
D sub
1
Physical specs
Length
30.5
Length unit
cm
Weight
0.8
Weight unit
kg
Width
24.4
Width unit
cm
Cooling
Fan headers
3
Heatsinks
VRM Heatsink, Chipset Heatsink
Pump headers
1
Thermal sensors
3
Audio
Channels
7.1
Codec
Realtek ALC892
Features
High Definition Audio, Audio Noise Guard
Power system
Power connectors
[{'type': '24-pin ATX', 'quantity': 1}, {'type': '8-pin EPS', 'quantity': 1}]
Power phases
6+2
Vrm solution
Digital PWM
