Experience reliable power protection with advanced features like ABM battery management technology and a true sine wave output. The Eaton 9PX5K ensures your critical equipment stays powered during outages, providing up to 3 minutes of backup time at full load. Its robust surge and spike protection safeguards against voltage fluctuations, while the hot-swappable battery design allows for easy maintenance without downtime. With remote management capabilities via USB, serial, and network ports, you can monitor and control your UPS from anywhere. The graphical LCD display offers real-time status updates, making it easy to manage and troubleshoot. Ideal for data centers, server rooms, and home offices, the 9PX5K delivers peace of mind with its comprehensive protection and efficient power management.
Specifications
Price
RM3,940.00
13 products
Specifications
Basic info
Brand
Eaton
Model
9PX
Product name
Eaton 9PX UPS
Manufacturer
Eaton
Type
Uninterruptible Power Supply
Manufacturing location
China
Form factor
Tower
Release date
2020-01-01
Dimensions
Depth
40.5
Depth unit
cm
Height
22.5
Height unit
cm
Weight
15.8
Weight unit
kg
Width
14.5
Width unit
cm
Power specifications
Capacity va
1500
Capacity watt
1350
Output waveform
Pure Sine Wave
Power factor
0.9
Transfer time
4ms
Input specifications
Frequency
50/60Hz
Frequency range
45-65Hz
Phase
Single
Voltage
230V
Voltage range
160-276V
Output specifications
Frequency
50/60Hz
Frequency range
45-65Hz
Number of outlets
8
Outlet type
IEC C13
Voltage
230V
Voltage range
220-240V
Battery specifications
Backup time
10-15 min
Capacity
9Ah
Hot swappable
Yes
Recharge time
4 hours
Replacement type
User-replaceable
Type
Sealed Lead-Acid
Voltage
12V
Protection features
Overload protection
Yes
Short circuit protection
Yes
Spike protection
Yes
Surge protection
Yes
Temperature protection
Yes
Voltage protection
Yes
Connectivity
Network port
Yes
Remote management
Yes
Serial port
Yes
Snmp support
Yes
Usb port
Yes
Display interface
Display type
LCD
Lcd display
Yes
Led indicators
Yes
Environmental
Energy saving features
Eco Mode
Noise level
40dB
Operating humidity
0-95%
Operating temperature
0-40°C
Warranty support
Certifications
CE, RoHS
Warranty period
2 tahun
Warranty type
Terhad
Additional features
Avr
Yes
Emergency power off
Yes
Power management software
Yes
Special features
Cold Start, Auto-Restart
