The Eaton 5P750R is a 1U rackmount UPS delivering 750VA/600W capacity with pure sine wave output. This network-manageable unit features 5x 5-15R outlets and operates at 120V with an 89-151V input range. It includes LCD display, USB/serial/network connectivity, and comprehensive protection against surges and spikes. Operating quietly at <45dB, it offers user-replaceable batteries and advanced features like AVR and remote power management.
Specifications
Price
RM1,730.00
14 products
Lazada
RM2,354.00
1 product
Specifications
Basic info
Brand
Eaton
Model
5P750R
Product name
Eaton 5P UPS
Manufacturer
Eaton
Type
UPS
Form factor
1U Rackmount
Dimensions
Depth
20
Depth unit
in
Height
1.7
Height unit
in
Weight
31.1
Weight unit
lb
Width
17.4
Width unit
in
Power specifications
Capacity va
750
Capacity watt
600
Output waveform
Sine wave
Power factor
0.8
Input specifications
Frequency
50-60 Hz
Frequency range
47-70 Hz (50 Hz system), 56.5-70 Hz (60 Hz system)
Voltage
120V
Voltage range
89-151 Vac
Output specifications
Frequency
50/60 Hz
Number of outlets
5
Outlet type
5-15R
Voltage
120V
Voltage range
102-132 Vac
Battery specifications
Replacement type
User-replaceable
Type
Sealed lead-acid
Protection features
Overload protection
Yes
Short circuit protection
Yes
Spike protection
Yes
Surge protection
Yes
Temperature protection
Yes
Voltage protection
Yes
Connectivity
Network port
Yes
Remote management
Yes
Serial port
Yes
Snmp support
Yes
Usb port
Yes
Display interface
Display type
LCD graphical display
Lcd display
Yes
Environmental
Noise level
<45 dB at 1 meter
Operating humidity
0-90% non-condensing
Operating temperature
0° to 35°C
Warranty support
Certifications
UL 1778, UL 497A, cULus, IEC 62040-2, RoHS, CE, FCC Class B
Warranty period
3 years
Warranty type
Factory warranty with registration
Additional features
Avr
Yes
Emergency power off
Yes
Power management software
Yes
Special features
ROO/RPO rear terminal block connector for remote on/off and power off
