The Aux ASW-09CAR3DI is a high-efficiency split air conditioner designed for residential use. With a 5-star energy efficiency rating and CSPF of 4.2, it delivers 2.6kW cooling capacity, ideal for spaces 10-15 ping. Features R32 refrigerant and operates in temperatures from -7°C to 46°C. Offers quiet operation (22-42dB) with advanced features including WiFi control, vertical/horizontal swing, and multiple operation modes. Includes anti-bacterial and fine dust filtration systems.
Specifications
Price
Lazada
RM522.00
10 products(1 item sold out)
RM870.00
20 products(2 items sold out)
Specifications
Basic information
Brand
Aux
Application
Residential
Type
Split Air Conditioner
Features
Air flow control
Horizontal swing
Yes
Vertical swing
Yes
Filtration system
Penapis Anti-Bakteria, Penapis Debu Halus
Operation modes
Penyejukan, Penghawa Dingin, Kipas, Auto
Protection features
Perlindungan Voltan Tinggi, Perlindungan Voltan Rendah, Perlindungan Arus Lebih
Smart features
Kawalan WiFi, Penjadualan Masa
Special functions
Tidur, Penjimatan Tenaga, Pencairan Fros Automatik
Technical parameters
Airflow
Maximum air flow rate
600
Noise level
High
42
Unit
dB
Low
22
Air flow rate unit
m³/h
Electrical
Power supply
220-240V, 50Hz
Connection wire
1.5mm²
Operating range
Temperature
Unit
°C
Minimum
-7
Maximum
46
Piping
Maximum height difference
10
Liquid pipe diameter
6.35
Gas pipe diameter
9.52
Pipe diameter unit
mm
Additional refrigerant charge
0.02
Maximum pipe length
15
Length unit
m
Refrigerant
Charge
0.55
Charge unit
kg
Type
R32
Installation
Installation area unit
m²
Minimum installation area
0.5
Mounting type
Dinding
Warranty
Coverage type
Terhad
Duration
1
Duration unit
tahun
Certifications
Safety certification
SIRIM
Performance specifications
Cooling
Unit
kW
Capacity range
Minimum
0.8
Maximum
3.2
Power consumption
0.78
Rated capacity
2.6
Coverage area
Unit
ping
Minimum
10
Maximum
15
Dehumidification
Unit
l/h
Capacity
1.2
Energy efficiency
Annual power consumption
850
Energy efficiency rating
5
Power consumption unit
kWh/year
Cooling seasonal performance factor
4.2
